33014T108.8/DB Tapered roller bearings& single row& matched back-to-back
Dimensions: Bore (Inner) Diameter: 70 mm; Outer Diameter: 110 mm; Width (Thickness): 108.8 mm;

33014T108.8/DB
REQUEST FOR QUOTE
* *
Send
Product Attributes
Product Number33014T108.8/DB
Bore diameter70 mm
Outside diameter110 mm
Total width108.8 mm
Shoulder diameter of inner ring88.9 mm
Width of outer ring97.8 mm
Chamfer minimum dimension of inner ring (r1,2)1.5 mm
Basic dynamic load rating (Cr)273 kn
Basic static load rating (Cor)400 kN
Fatigue load limit (Pu)45.5 kN
Reference speed3800 r/min
Limiting speed5600 r/min
Mass3.05 kg
Limiting value (e)0.28
Axial load factor (Y0)2.5
Minimum diameter of shaft abutment (db)80 mm
Minimum width of space required in housing on small side face (C5.5 mm
Width of spacer ring (l)46.8
Width of lubrication groove (b)10
Diameter of lubrication hole (K)4.5
Chamfer minimum dimension of outer ring (r5)0.6
Axial load factor (Y1)2.4
Axial load factor (Y2)3.6
Maximum Radius of housing fillet (ra)1.5
Maximum Radius of shaft fillet (rc)0.6
33014T108.8/DB
Print PDF
Request a 3D CAD Model if you need special bearings - design custom bearings
What are the types of Tapered roller bearings 33014T108.8/DB ? Tapered roller bearings& single row& matched back-to-back Manufacturing Service . Get Your Free, Instant price, design review, stock and delivery time.
Min.Order Quantity:Negotiation
Price:Negotiation
  • Fast Delivery     √
  • Best Quality       √
  • Good Price        √
