32022T84 X/DB Tapered roller bearings& single row& matched back-to-back
Dimensions: Bore (Inner) Diameter: 110 mm; Outer Diameter: 170 mm; Width (Thickness): 84 mm;

32022T84 X/DB
REQUEST FOR QUOTE
* *
Send
Product Attributes
Product Number32022T84 X/DB
Bore diameter110 mm
Outside diameter170 mm
Total width84 mm
Shoulder diameter of inner ring140 mm
Width of outer ring66 mm
Chamfer minimum dimension of inner ring (r1,2)2.5 mm
Basic dynamic load rating (Cr)494 kn
Basic static load rating (Cor)780 kN
Fatigue load limit (Pu)80 kN
Reference speed2400 r/min
Limiting speed3600 r/min
Mass6.5 kg
Limiting value (e)0.43
Axial load factor (Y0)1.6
Minimum diameter of shaft abutment (db)123 mm
Minimum width of space required in housing on small side face (C9 mm
Width of spacer ring (l)8
Width of lubrication groove (b)4.5
Diameter of lubrication hole (K)3
Chamfer minimum dimension of outer ring (r5)0.6
Axial load factor (Y1)1.6
Axial load factor (Y2)2.3
Maximum Radius of housing fillet (ra)2.5
Maximum Radius of shaft fillet (rc)0.6
32022T84 X/DB
Print PDF
Request a 3D CAD Model if you need special bearings - design custom bearings
What are the types of Tapered roller bearings 32022T84 X/DB ? Tapered roller bearings& single row& matched back-to-back Manufacturing Service . Get Your Free, Instant price, design review, stock and delivery time.
Min.Order Quantity:Negotiation
Price:Negotiation
  • Fast Delivery     √
  • Best Quality       √
  • Good Price        √
