4304 ATN9 Deep Groove Ball Bearings
Dimensions: Bore (Inner) Diameter: 20 mm; Outer Diameter: 52 mm; Width (Thickness): 21 mm;

4304 ATN9
REQUEST FOR QUOTE
* *
Send
Product Attributes
Bearing Type Ball
For Load Direction Radial
Construction Double Row
Seal Type Open
Part Number 4304 ATN9
For Shaft Diameter 20 mm
Bore Dia (d) 20 mm
Bore Dia Tolerance -0.01mm to 0
For Housing ID 52 mm
Outer Dia (D) 52 mm
Outer Dia Tolerance -0.013mm to 0
Width (B) 21 mm
Width Tolerance -0.120mm to 0
Ring Material 52100 Chrome steel
Ball Material 52100 Chrome steel
Cage Material Nylon 66 (PA66)
Dynamic Load Rating (C) (KN) 23.4
Static Load Rating (C0) (KN) 16
Reference Speed (X1000 RPM) 12
Limiting Speed (X1000 RPM) 22
Lubrication Required
Shaft Mount Type Press Fit
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Trade No. C0
Radial Clearance 0.006mm to 0.020mm
RoHS Compliant
Weight (grams) 210
4304 ATN9
Print PDF
Request a 3D CAD Model if you need special bearings - design custom bearings
What are the types of ball bearings 4304 ATN9 ? Deep Groove Ball Bearings Manufacturing Service . Get Your Free, Instant price, design review, stock and delivery time.
Min.Order Quantity:Negotiation
Price:Negotiation
  • Fast Delivery     √
  • Best Quality       √
  • Good Price        √
