NU 416
Single row cylindrical roller bearing
Dimensions: Bore (Inner) Diameter: 80 mm； Outer Diameter: 200 mm； Width (Thickness): 48 mm;
REQUEST FOR QUOTE
Product Attributes
| Product Number | NU 416 |
| Bore diameter | 80 mm |
| Outside diameter | 200 mm |
| Width | 48 mm |
| Basic dynamic load rating | 303 kN |
| Basic static load rating | 320 kN |
| Fatigue load limit | 39 kN |
| Reference speed | 3800 r/min |
| Limiting speed | 4500 r/min |
| Mass | 7.25 kg |
| Shoulder diameter of inner ring | – |
| Shoulder diameter of outer ring | 158.1 mm |
| Raceway diameter | 110 mm |
Print PDF
Request a 3D CAD Model
if you need special bearings - design custom bearings
