T01-00325NAA
TT Thin Section Turntable Bearings
Dimensions: Bore (Inner) Diameter: 2.422"； Outer Diameter: 4.000"； Width (Thickness): 0.25";
REQUEST FOR QUOTE
Product Attributes
| Bearing Type | Ball | |
| For Load Direction | Four Point | |
| Construction | Single Row | |
| Part Number | T01-00325NAA | |
| gear | Internal gear | |
| Bore Dia (d) | 2.422 | |
| Outer Dia (D) | 4.000 | |
| Inner Land | 3.148 | |
| Oueter Land | 3.356 | |
| Width (B) | 0.25 | |
| Inner Bolt Circle | 2.813 | |
| Number of holes | 9 | |
| Outer Bolt Circle | 3.688 | |
| Gear pitich diameter(in) | 2.453 | |
| Number of teeth | 157 | |
| Dynamic(lbs) | Thrust | 1;010 |
| Radial | 640 | |
| Moment | 780 | |
| Static (lbs) | Thrust | 2;470 |
| Radial | 990 | |
| Moment | 1;600 | |
| Static Torque | 5.5 | |
| Weight (lbs) | 0.50 | |
Print PDF
Request a 3D CAD Model
if you need special bearings - design custom bearings
What are the types of Thin Section Bearings T01-00325NAA ? TT Thin Section Turntable Bearings Manufacturing Service . Get Your Free, Instant price, design review, stock and delivery time.
Min.Order Quantity:NegotiationPrice:Negotiation
