MTO-210T
Kaydon Slewing Bearings
Dimensions: Bore (Inner) Diameter: 8.268"； Outer Diameter: 14.37"； Width (Thickness): 8.268";
Product Attributes
| Specifications | |
| Part Number | MTO-210T |
| Moment Load Rating (Crm) | 44,500ft-lbs | 198.661KN |
| Bearing Types | Slewing Ring Bearing |
| Outline Dimensions and Weight | |
| Outside Diameter of Outer Ring (Do) | 14.370" | 365mm |
| Inside Diameter of Inner Ring (di) | 8.268" | 210.01mm |
| Height of Overall Bearing Assembly (H) | 1.575" | 40.01mm |
| Height of Inner Ring (Hi)/Height of Outer Ring (Ho) | 1.496" | 38mm |
| Approximate Weight (lbs) | 38lbs | 17.236KG |
| Mounting Holes | |
| Bolt Circle in Outer Ring (Lo) | 13.190" | 335.03mm |
| Number Holes in Outer Ring (no) | 16 |
| Size of Hole in Outer Ring (Bo) | 5/8-11 |
| Bolt Circle in Inner Ring (Li) | 9.449" | 240mm |
| Number Holes in Inner Ring (ni) | 20 |
| Size of Hole in Inner Ring (Bi) | 5/8-11 |
| Gear Data | |
| Pressure Angle of Gear Teeth (α) | - |
| Tooth form | - |
| Pitch diameter of gear(D2) | - |
| Diametral pitch(Pd) | - |
| Number of gear teeth(z2) | - |
| Face width of gear teethαb2) | - |
Print PDF
Request a 3D CAD Model
if you need special bearings - design custom bearings
What are the types of Slewing Bearings MTO-210T ? Kaydon Slewing Bearings Manufacturing Service . Get Your Free, Instant price, design review, stock and delivery time.
Min.Order Quantity:NegotiationPrice:Negotiation
